1"-6" HYDRAULIC ROLL GROOVING MACHINE (TWG-VA-R)
This machine is designed to roll form grooves in most types of piping including seamless steel tubing, galvanized pipes, plastic-lined pipes and stainless steel pipes ETC, to facilitate the installation of circular pipe constructions. It’s an ideal tool for construction industry and pipeline construction sectors.
PRODUCT INTRODUCTION
● TWG-VA-R Hydraulic roll grooving machine is designed for grooving 1"-6" steel pipe.
● Simple design of the carriage, easy to be assembled and transported.
● Equipped with integral hydraulic pump and stroke limitation device to control the depth of grooves precisely and effectively.
SPECIFICATIONS
● Capacity: 1"-6" (Φ33- Φ168) SCH40 steel pipe. 1"-6" (Φ33- Φ168) SCH10S SCH5S SCH10 SCH5 thin wall steel pipe.
● Max. wall thickness: 6mm.
● Output RPM: 23rpm.
● G. W: 96kgs.
● Packaging size: 95x53x65(cm).
Standard Equipment | |||
*For SCH40 steel pipe | |||
Art. No. | Description | N.W(kgs) | Ref No. |
09.02.040 | Pipe stand | 6.5 | (1) |
03.01.11.002 | Knurl wheel Φ 33-Φ 48 | 0.895 | (2) |
03.01.11.003 | Knurl wheel Φ 57-Φ 89 | 1.1 | (3) |
03.01.11.004 | Knurl wheel Φ 108-Φ 168 | 1.605 | (4) |
03.01.11.005 | Pinch roller Φ 33-Φ 48 | 0.685 | (5) |
03.01.11.006 | Pinch roller Φ 57-Φ 168 | 0.46 | (6) |
*Reminding: Please select TWG-9A if groove large number of 6 inch pipes | |||
Optional Equipment | ||
*For SCH10S SCH5S SCH10 SCH5 thin wall steel pipe | ||
Art. No. | Description | N.W(kgs) |
09.03.042 | Thin wall knurl wheel Φ 33-Φ 48 | 1.65 |
09.03.043 | Thin wall knurl wheel Φ 57-Φ 89 | 1.115 |
09.03.044 | Thin wall knurl wheel Φ 108-Φ 168 | 1.995 |
Motor Parameter | ||
Phase | Voltage | Frequency |
Single phase | 110/120/220/230/240V | 50/60Hz |
Three Phase | 220/380/ 415/ 440V | 50/60 Hz |
*Before turn on the machine pls make sure ground wire is grounding. | ||
OUR ADVANTAGES
1. Competitive price: direct manufacturer, reducing all unnecessary cost for you.
2. Good service: Customer is first
3. Professional team:16 years foreign customers service experience. We identified as state-level high-tech enterprises in 2010 years.
4. Globally acceptable quality: The products offered by us are thoroughly examined by our experienced professionals to ensure their durability, reliability and long service life. Tuwei is ISO9001:2008 certified company. We got the CE certifications of all the exported products.
SYSTEM AUTHENTICATION AND CE CERTIFICATE
INVENTION PATENT
FAQ
Q1: We would like to know if you are a manufacturer or a trading company?
A1: We are a professional pipe tools factory while roll grooving machine, pipe cutting machine and hole cutting machine are our main products.
Q2: How long is your delivery time?
A2: Generally 15 days after the down payment. OEM delivery time depends.
Q3:What is your terms of payment?
A3:Payment<=USD5000, 100% in advance. Payment>=USD5000, 30% T/T in advance, 70% T/T before shipment.
Q4: MOQ
A4: 1 set machine.
Q5: What is your terms of delivery?
A5: EXW, FOB, CFR, CIF.
Q6: What can I get the quotation?
A6: We usually quote within 24 hours after we get your inquiry. If you are urgent, you can give me your email so that we will regard your inquiry priority.
If you have any inquiry, please do not hesitate to contact us!
